1 2 4 6 8 Cores Electric Wire and Cable with PVC Jacket Industrial Grade
Product Details:
| Place of Origin: | china |
| Brand Name: | sihuan |
| Model Number: | electric wire 2x2.5mm2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000m |
|---|
|
Detail Information |
|||
| Average Thickness: | 0.76 | Core Number: | 2-60 |
|---|---|---|---|
| Jacket Material: | Nylon | Jacket: | PVC |
| Material: | Copper | Sample: | Provided |
| Lead Time: | 7-15days | Package Gross Weight: | 250.000kg |
Product Description
Product Descrip
Specifications & Performance Table for 2×2.5mm² Household Electrical Wire
| Parameter | Specification |
|---|---|
| Conductor Material | High-purity copper (99.9%) |
| Conductor Size | 2.5 mm² (per core) |
| Number of Cores | 2 (Live & Neutral) |
| Insulation Material | PVC (Polyvinyl Chloride) |
| Voltage Rating | 300/500V |
| Max Operating Temp. | 70°C (158°F) |
| Current Capacity | ~25A (depends on installation conditions) |
| Flexibility | Class 2 stranded conductor (flexible) |
| Outer Sheath Color | White/Black/Red (customizable) |
| Standards Compliance | IEC 60227, BS 6004, CE, RoHS |
| Fire Resistance | Flame-retardant (IEC 60332-1) |
| Applications | Home wiring, sockets, lighting circuits, appliances |
Key Features (English Description)
-
High Conductivity – Oxygen-free copper ensures low resistance and efficient power transmission.
-
Durable Insulation – PVC sheath protects against abrasion, moisture, and short circuits.
-
Safety Certified – Complies with international electrical safety standards.
-
Flexible & Easy to Install – Stranded conductors allow smooth bending in conduits.
-
Wide Compatibility – Suitable for residential wiring, extensions, and fixed installations.
Representative Image
(Note: This is a conceptual illustration; actual wire appearance may vary.)
(Replace with actual image link)
Additional Notes:
-
Installation Tip: Use with 16–20A circuit breakers for optimal protection.
-
Certifications: Check for local standards (e.g., UL, VDE, or SABS for regional markets).
